- 116 -UMC100-FBP
Universal Motor Controller
UMC100-FBP
Technical Description
FieldBusPlug / Issue: 03.2012
DX1xx / VI15x Status Codes
Three LEDs show the module status. The following table explains the status messages.
Status Explanation
Green LED Yellow LED Red LED
On On On Self-test during start-up
Flashing Off On Communication with UMC was interrupted. Relay outputs
switched off.
Possible cause: Wiring between UMC and IO module broken.
Possible corrective measure: Check wiring and check that the
module was activated in the UMC configuration.
Flashing Off Off Waiting for communication with UMC. Module is ready.
Possible cause: Wiring between UMC and IO module broken.
Possible corrective measure: Check wiring and check that the
module was activated in the UMC configuration.
On Off Off Cyclic data exchange with UMC. No diagnosis.
On Flashing Off Cyclic data exchange with UMC. Diagnosis exists.
Irrelevant Flashing Hardware defect.
Possible corrective measure: Replace module.
Flashing
Replacing a UMC100
The UMC and the current transformer are calibrated together in the ABB factory. Therefore the UMC must
be completely replaced.
The UMC can be disconnected from the FieldbusPlug without disturbing the fieldbus communication and
the other slaves. The FieldbusPlug is supplied via the voltage conducted together with the bus lines. The
FieldbusPlug keeps the actual slave address and informs the control system that the connected device is
disconnected.
Set the parameters in the new UMC depending on your parameterisation concepts.
If you stored the parameters and/or your user defined application in the UMC100-
PAN you can just download them from the panel back to the UMC100.
After mounting and connecting a new UMC, the communication starts up again.
Replacing a DX1xx IO Module
DX1xx modules are automatically parameterized by the UMC if the communication between UMC and IO
module has been established. No further user actions are required.
Replacing a VI15x Module
VI15x modules are automatically parameterized by the UMC if the communication between UMC and
module has been established. No further user actions are required.
Requesting Support
If you need support we kindly ask you to contact your local ABB representative using the template provid-
ed at the end of this manual.
Check the Configuration
The menu option "Changed parameters" in the Service menu displays all parameters with changed set-
tings (i.e., parameters with settings different from the default settings). Using this function you can quickly
check whether all parameters are set correctly
