- 129 - UMC100-FBP
Universal Motor Controller
UMC100-FBP
Technical Description
FieldBusPlug / Issue: 03.2012
Communication Parameters
Para-
meter
Number
Parame-
ter Name
Description, Explanations Options Adjusta-
ble via
17 Address
check
Enable check if bus address stored in
the UMC is the same as the one stored
in the FieldbusPlug.
Off (0), On (1) All
18 Busfault
reaction
UMC behaviour in the event of a bus
fault.
Motor Off (0),
Retain (1),
Start For (2),
Start Rev (3)
All
- Bus
address
Fieldbus address. Depending on the
FieldbusPlug used, the permitted ad-
dress range is smaller than the one
allowed here.
0,1,2,3 ...255 UMC100-
PAN
PBDTM
- Parameter
lock
Prevents any parameter changes if set
to On.
Unlocked (0), Locked (1) UMC100-
PAN
IO Module Parameters
DX111 / DX122 Parameters
Param-
eter
Number
Parameter
Name
Description, Explanations Options Adjustable via
8 Missing
Module
Reaction
Defines if the UMC creates a
fault or a warning in case of a
missing IO module.
Error (0)
Warning (1)
All
1 DX1xx En-
abled
Specify if the module is con-
nected to UMC
Off (0), On (1) All
151 DX1xx DI
delay
Input delay in ms assuming a
line frequency of 50Hz
DX111: 3...200ms
Values are rounded up to the
next multiple of 3.
E.g.:
7,8,9 -> 9 ms delay
In addition to the software
delay a fix hardware delay of
about 4ms must be considered.
DX122: 3...200ms
Values are rounded to the next
multiple of 10. Values below 20
are rounded up to 20.
E.g.:
3...20: 20 ms delay
81...90: 90 ms delay
All excluding
GSD-PDQ22
152 DX1xx AO
type
Hardware type of the ana-
logue output on the DX1xx
module.
0 - 20mA (0),
4 - 20mA (1),
0 - 10mA (2),
0 - 10V (3)
All excluding
GSD-PDQ22
153 DX1xx AO
error
reaction
Reaction if the AO detects
a short-circuit or wire break
condition.
Disabled (0),
Trip (1),
Warning (2)
All excluding
GSD-PDQ22
