ABB UMC100-FBP User Manual

- 135 - UMC100-FBP
Universal Motor Controller
UMC100-FBP
Technical Description
FieldBusPlug / Issue: 03.2012
All Parameters Sorted by Parameter Number
No Name Parameter Group
1 DX1xx Enabled IO Module Param-
eters
4 VI15x Enabled IO Module Param-
eters
8 Missing Module React. IO Module Param-
eters
9 PTC, Thermistor Protection
10 Earth Flt Trip Level Protection
11 Earth Flt Trip Delay Protection
12 Earth Flt Warn Level Protection
13 Earth Flt Warn Delay Protection
14 Fault Auto Reset Motor Management
15 Emergency Start Motor Management
16 Earth Flt Detection Protection
17 Address Check Communication
18 Busfault Reaction Communication
19 Enable Custom Logic Motor Management
20 Control Function Motor Management
21 Rev Lock-Out Time Motor Management
22 Checkback Motor Management
23 Checkback Time Motor Management
24 YD Change-Over Mode Motor Management
25 YD Starting Time Motor Management
27 Fault Output Motor Management
28 Trip Class Protection
29 Setting Ie 1 Protection
30 Setting Ie 2 Protection
31 Current Factor Protection
32 Low Curr Trip Level Protection
33 Low Curr Trip Delay Protection
34 Low Curr Warn Level Protection
35 Low Curr Warn Delay Protection
36 High Curr Trip Level Protection
37 High Curr Trip Delay Protection
38 High Curr Warn Level Protection
39 High Curr Warn Delay Protection
40 Locked Rotor Level Protection
41 Locked Rotor Delay Protection
42 Phase Loss Prot. Protection
43 Current Imb Trip Level Protection
44 Current Imb Warn Level Protection
45 Phase Reversal Protection
46 Check Phase Se-
quence
Protection
48 Cooling Mode Protection
49 Cooling Time Protection
50 Restart Level Protection
No Name Parameter Group
51 Aux Inp 1 Ack Mode Aux Input Block
52 Aux Inp 2 Ack Mode Aux Input Block
53 Aux Inp 3 Ack Mode Aux Input Block
54 Aux Inp 4 Ack Mode Aux Input Block
55 Aux Inp 5 Ack Mode Aux Input Block
56 Aux Inp 6 Ack Mode Aux Input Block
57 Aux Inp 1 Reaction Aux Input Block
58 Aux Inp 2 Reaction Aux Input Block
59 Aux Inp 3 Reaction Aux Input Block
60 Aux Inp 4 Reaction Aux Input Block
61 Aux Inp 5 Reaction Aux Input Block
62 Aux Inp 6 Reaction Aux Input Block
63 Aux Inp 1 Message L1 Aux Input Block
64 Aux Inp 1 Message L2 Aux Input Block
65 Aux Inp 2 Message L1 Aux Input Block
66 Aux Inp 2 Message L2 Aux Input Block
67 Aux Inp 3 Message L1 Aux Input Block
68 Aux Inp 3 Message L2 Aux Input Block
69 Aux Inp 4 Message L1 Aux Input Block
70 Aux Inp 4 Message L2 Aux Input Block
71 Aux Inp 5 Message L1 Aux Input Block
72 Aux Inp 5 Message L2 Aux Input Block
73 Aux Inp 6 Message L1 Aux Input Block
74 Aux Inp 6 Message L2 Aux Input Block
75 Aux Inp 1 Delay Aux Input Block
76 Aux Inp 2 Delay Aux Input Block
77 Aux Inp 3 Delay Aux Input Block
78 Aux Inp 4 Delay Aux Input Block
79 Aux Inp 5 Delay Aux Input Block
80 Aux Inp 6 Delay Aux Input Block
81 Custom App Parameter Motor Management
82 Invert DI Start Inp. Motor Management
83 Invert DI Stop Inp. Motor Management
86 Inching DI Start Inp Motor Management
90 Loc 1 Start Bus Cyc Motor Management
91 Loc 1 Stop Bus Cyc Motor Management
92 Loc 1 Start DI Motor Management
93 Loc 1 Stop DI Motor Management
94 Loc 1 Start LCD Motor Management
95 Loc 1 Stop LCD Motor Management
96 Loc 1 Start Bus Acyc Motor Management
97 Loc 1 Stop Bus Acyc Motor Management
98 Auto Start Bus Cyc Motor Management
99 Auto Stop Bus Cyc Motor Management
100 Auto Start DI Motor Management
