- 125 - UMC100-FBP
Universal Motor Controller
UMC100-FBP
Technical Description
FieldBusPlug / Issue: 03.2012
Protection Parameters
Para-
meter
Number
Parameter
Name
Description, Explanations Options Adjust-
able via
Protection Parameters
29 Setting I
e1
Nominal current of motor for speed
1.
0.24...3200A in steps of
0.01A
Default: 0.50A
Unscaled: 24...320000
Example: A value of 24
means 240mA
All
30 Setting I
e2
Nominal current of motor for speed
2.
See above All
28 Trip class Class according to EN/IEC
60947-4-1
Class 5 (0),
Class 10 (1),
Class 20 (2),
Class 30 (3),
Class 40 (4)
All
31 Current factor Current factor when using an ex-
ternal CT or when the motor wires
are fed through the UMC CTs more
than once.
2,3,4,5, 100 ... 64000
Examples:
•3: motor wires are fed
through 3 times
•100: internal CT, no mul-
tiple feed-throughs
•12500 means a factor of
125:1
All
9 PTC, Therm-
istor
Setting for the built-in PTC (Therm-
istor) protection. The reaction to
hardware cannot be set separately.
Disabled (0),
Trip(1),
Warning(2)
All
48 Cooling mode After a thermal overload trip which
was triggered through the thermal
motor model the cooling duration
can be defined as fixed time or as
a percentage of the thermal load
level (0%=cold, 100% = trip)
Time (0),
Restart Level (1)
All
49 Cooling time The time a restart is inhibited fol-
lowing a thermal overload trip trig-
gered by the thermal motor model
30 ... 64000s
Default value: 120s
All
50 Restart level
in %
Below this threshold a motor re-
start is accepted.
10...100%
Default value: 30%
All ex-
cluding
GSD-
PDQ22
