ABB UMC100-FBP User Manual

- 117 - UMC100-FBP
Universal Motor Controller
UMC100-FBP
Technical Description
FieldBusPlug / Issue: 03.2012
A1 Parameters and Data Structures on a Fieldbus
In the following chapter you find a detailed description of all UMC parameters, the format of the com-
mand monitoring and diagnosis telegrams. Furthermore the information is provided of how the UMC data
is mapped to the different FieldbusPlugs
The UMC100 version R0101 offers additional monitoring and command data compared to the version
R0100/R0200. The data was added to previously unused positions in the telegrams to keep backwards
compatibility.
The tables below represents the data allocation as realised with the built-in standard applications. It may
differ for customer-specific applications!
Monitoring Data
Word Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit1 Bit 0
0
0
Summary
Warning
Summary
Fault
Local
Control
3
Reverse
Lockout
Time
3
Overload
warning
Run For-
ward
1,3
/
Opening
2,3
Off
3
Run Re-
verse
1,3
/
Closing
2,3
1
UMC100
DI5
UMC100
DI4
UMC100
DI3
UMC100
DI2
UMC100
DI1
UMC100
DI0
Run
Fast
Forward
4)
-
1 2, 3 Motor Current in % of I
e
(0% - 800%)
2 4, 5 Analogue Word (Thermal Load: 0% - 100%)
3 6, 7 Analogue Word (Time to trip in seconds)
4 8, 9 Analogue Word (Time to restart in seconds)
5 10.11 Analogue Word (Active power in selected scale)
6
12
DX1xx
DI7
DX1xx
DI6
DX1xx
DI5
DX1xx
DI4
DX1xx
DI3
DX1xx
DI2
DX1xx
DI1
DX1xx
DI0
13
- -
Run Time
Exceeded
1
Out of
Position
1
Torque
Open
1
Torque
Closed
1
End Pos
Open
1
End Pos
Closed
1
7
14
U Imbal.
warn
U Imbal.
trip
Undervol-
tage warn
Undervol-
tage trip
Underpo-
wer warn
Underpo-
wer trip
Overpo-
wer warn
Overpo-
wer trip
15
Earth
fault
warning
Earth fault
trip
Cooling
t
ime run-
ning
- THD
warning
No start
possible
5)
1 start
left
5)
More
than 1
start left
5)
Command Data
Word Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit1 Bit 0
0
0
- Fault
Reset
Auto
Mode
3
Prepare
Emergency
Start
- Run For-
ward
1.3
/
Opening
2,3
Off
3
Run Re-
verse
1,3
/
Closing
2,3
1
UMC100
DO2
UMC100
DO1
UMC100
DO0
UMC100
24VDC Out
- - Run
Fast
Forward
4)
-
1
2
VI15x
DO0
- - - DX1xx
DO3
DX1xx
DO2
DX1xx
DO1
DX1xx
DO0
3 - - - - - - - -
2 4, 5 Analogue Word
3 6, 7 Analogue Word
4 8,9 Analogue Word
5 10,11 Analogue Word
1)
Not for Actuator 1 ... 4
2)
Only for Actuator 1 ... 4
3)
Not for Overload Relay and Transparent
4)
Only for Pole-Changing Starter
5)
If start limit function is used
