- 151 - UMC100-FBP
Universal Motor Controller
UMC100-FBP
Technical Description
FieldBusPlug / Issue: 03.2012
EMC UMC100 and DX1xx / VI15x Modules
Measurement of radiated and conducted interfe-
rence according to EN61131-2 CISPR16-2-3
Class A
Electrostatic discharge accoring to IEC 61000-6-2 8 kV air discharge
6 kV contact discharge
Radiofrequency electromagnetic field according to
IEC 61000-4-3
10 V/m
Fast transient bursts according to EN61000-4-4 2 KV power supply
High energy surges according to EN61000-4-5 1/0,5 kV CM/DM
Conducted radio frequency interference according
to EN61000-4-6
10 V
VI15x
Measurement of radiated and conducted interfe-
rence according to EN61131-2 CISPR16-2-3
Class A
Electrostatic discharge accoring to IEC 61000-6-2 8 kV air discharge
6 kV contact discharge
Radiofrequency electromagnetic field according to
IEC 61000-4-3
10 V/m
Fast transient bursts according to EN61000-4-4 2 kV power supply
High energy surges according to EN61000-4-5 1/0,5 kV CM/DM power supply
2/1 kV CM/DM L1/L2/L3 voltage inputs
Conducted radio frequency interference according
to EN61000-4-6
10 V
Damped oscillatory wave acc. to
EN61000-4-18
Only voltage inputs L1/L2/L3:
2.5 kV / 1 kV CM / DM
Immunity low frequency harmonics acc. to
EN61000-4-11
Power supply: 50 ... 12 kHz, 3V
Voltage Inputs L1, L2, L3
Overvoltage category III in grounded networks
II in ungrounded networks
Nominal input range (line to line voltage) 150 - 690 V AC
Uimp U
imp
=8 kV
Voltage measuring in the nominal input range +/- 2 %
Power factor: 0.4 ... 0.95 +/- 3.5 % for I > 0.75A
Real power kW +/- 5 % typ.
Energy kWh +/- 5 % typ.
THD %
Rated Operational Voltage Ue 690 V AC line to line
Usage in grounded/ungrounded networks VI155 can be used in grounded and ungrounded
networks
VI150 can only be used in grounded networks.
See installation instructions in section 2.
Voltage supply cables
Note
that the connection cables for voltage measure-
ment may require additional cable protection
