Chapter 3 91
Removing the LCD Bezel
1. See “Removing the LCD Module” on page 84.
2. Remove the four screw covers and four screws securing the front bezel to the LCD cover.
3. Starting from the inside top edge, pry the bezel away from the panel. Continue moving along the top,
prying the bezel away from the LCD Module. If necessary, use a plastic pry to release the corners of the
bezel.
4. Release the bottom edge of the bezel, separating the securing clips.
Step Size Quantity Screw Type
LCD Bezel M2.5*4 4
p
