Acer Aspire 5534 Series Service Guide

Chapter 3 143
Replacing the ODD
1. Insert the hook on the ODD bezel as shown.
2. Slide the securing clip of the ODD bezel into the slot on the ODD module. An audible click indicates the
hook has engaged.
3. Insert the two screws to secure the ODD bracket in place.
Step Size Quantity Screw Type
ODD Bracket M2*3 2
