Acer Aspire 5534 Series Service Guide

80 Chapter 3
Removing the DC-In Cable
1. See “Removing the I/O Board” on page 77.
2. Remove the DC-In Socket from the well on the bottom cover.
3. Remove the DC cable from the securing clips as shown.
NOTE: If replacing the DC cable, the mainboard must be lifted to access the connector. See “Removing the
Mainboard” on page 81 for instructions.
