118 Chapter 3
Replacing the Mainboard
1. Connect the DC-In Cable to the mainboard.
2. Reach under the mainboard to plug in the LVDS cable.
3. Insert the Mainboard right side first, aligning the I/O ports with the Lower Cover.
