Acer Aspire 5534 Series Service Guide

Chapter 3 121
Replacing the I/O Board
1. Connect the I/O Board Cable to the I/O Board.
2. Apply the adhesive to secure the I/O Board cable to the Lower Cover.
3. Insert the board into the lower cover so the white tab is under the securing clip in the lower cover, taking
care to align the screw holes.
