Acer Aspire 5534 Series Service Guide

14 Chapter 1
Hardware Specifications and Configurations
Processor
Processor Specifications
CPU Fan True Value Table
Throttling 50%: On= 90°C; OFF=80°C
OS shut down at 95°C; H/W shut down at 87°C
North Bridge Specifications
South Bridge Specifications
Item Specification
CPU type AMD S1g1 processor
CPU package 638-pin lidless micro PGA package.
Chipset AMD RS780MN Northbridge
AMD SB710 A13 Southbridge
Item
CPU
Speed
Cores
Mfg.
Tech
Cache
Size
Package
Core
Voltage
Acer P/N
L310 1.2 GHz 2 65 nm 1 MB Micro-
PGA
Variable KC.AL002.310
TF20 1.6 GHz 1 65 nm 512 kB Micro-
PGA
Variable KC.ATF02.200
CPU Temperature
(Celsius)
Fan Speed (RPM) SPL Spec (dBA)
45 3100 28
50 3500 31
55 3900 34
63 4400 37
75 4700 40
Item Specification
Chipset AMD RS780MN chipset.
Package 21MM 528-FCBGA
Features • CPU HyperTransport™ Interface
• Support for DDR2 memories up to DDR2-800
• ATI HyperMemory™
• Supports PCI-E Gen2 (version 2.0).
• A-Link Express II Interface
Item Specification
Chipset AMD SB710 A13 chipset
Package 21MM 528-FCBGA

Acer Aspire 5534 Series Specifications

General

Brand	Acer
Model	Aspire 5534 Series
Category	Laptop
Language	English
