Acer Aspire 5534 Series Service Guide

Chapter 3 125
3. Adhere the mylar to the Media Board and insert the single screw to secure the Media Board to the Lower
Cover.
Replacing the Speaker Modules
1. Place the right side speaker onto the Lower Cover as shown.
Step Size Quantity Screw Type
Media Board M2.5*3 1
