68 Chapter 3
Removing the Touchpad Bracket
1. See “Removing the Button Board” on page 66.
2. Remove the single screw securing the Touchpad Bracket to the Upper Cover.
3. Pull the bracket up from under the securing tabs along the top edge.
NOTE: It may be necessary to use a tool to first push the securing tabs back so that the bracket may be more
readily removed.
4. Slide the Touchpad Bracket out from the slots in the upper cover.
Step Size Quantity Screw Type
TouchPad Bracket M2*3 1
To Next Page
