Power
The Power screen allows the user to configure CPU and power management options.
The table below describes the parameters in this screen. Settings in boldface are the default and suggested
parameter settings.
Parameter Description Submenu Items
Advanced CPU
Control
Enter the Advanced CPU Control menu. • IST Configuration
• Thermal Mode
• CMP Support
• Use NX capability
• C-State support
• Enhanced C-States Enable
• Pop Up Support
• Pop Down Support
•Hard C4E
• Bi-directional PROCHOT#
• ACPI 3.0 T-States
• DTS Enable
• Thermal Trip Points Setting
(Throttle On Temp.)
ACPI S3 Enable or Disable ACPI S1/S3 Sleep State. N/A
ACPI S3 Enable or Disable ACPI S1/S3 Sleep State. N/A
Wake on PME Disable or Enable wake up when the
system power is off and a PCI Power
Management Enable wake up event occurs.
N/A
Auto wake on S5 Disable or Enable auto wake up by date
and time or at a fixed time everyday.
N/A
