Acer Aspire 5534 Series Service Guide

Chapter 3 95
Removing the LCD Panel
1. See “Lift up the bezel and remove it from the LCD Module.” on page 92.
2. Remove the four screws securing the LCD Panel to the LCD Module.
3. Lift the LCD Panel out of the LCD Module front edge first.
Step Size Quantity Screw Type
LCD Panel M2*3 4
