Chapter 3 45
External Module Disassembly Process
NOTE: The product previews seen in the disassembly procedures may not represent the final product color or
configuration.
External Modules Disassembly Flowchart
Screw List
Step Screw Quantity Part No.
HDD Module M2.5*3 2 86.PEA02.003
HDD Carrier M3*3 4 86.PEA02.008
WLAN Board M2*3 1 86.PEA02.001
ODD Module M2.5*3 1 86.PEA02.009
ODD Bracket M2*3 (silver) 2 86.PEA02.002
Disconnect power
and signal cables
from system
Remove
Battery
Turn off system
and peripherals
power
Remove
DIMMs
Remove
WLAN
Remove
HDD
Remove
ODD
Remove
Lower Covers
Remove
Dummy Card
To Next Page
