Acer Aspire Z5600 Series User Manual

10 Chapter 1
Hardware Specifications and Configurations
Processor
Item Specification
CPU type
• Intel Core™2 Quad Processor*
• Intel Core™2 Duo Processor*
• Intel Pentium Processor*
• Intel® Celeron® processor*
Core Logic
• North Bridge (Eaglelake G45)
• GTL+ interface (Front-side bus)
• Support Intel Yorkfield/Wolfdale Processor
• 800/1066/1333MHz transfer rate processor bus speed
• Integrated DRAM controller
• Dual-channel DDR3 SDRAM interface.
• Unified Memory Architecture, with 128 MB to 256MB of
the main memory configurable as display memory.
• Asynchronous FSB and Memory Controller.
• Supports Dual channel 800/1066 DDR3 SDRAM.
• Max 8GB memory addressability, for faster system.
• Serial ATA
• Support maximum four SATA 3.0Gb/s ports..
• South Bridge (ICH10)PCI bus Interface
• Supports PCI bus at 33MHz
• PCI Rev.2.3 specification support.
• Support for 64 bit addressing on PCI using DAC
protocol.SMBus: SM Bus Rev.2.0 compliant.
• Support Power management
• ACPI Specification 3.0 compliant power management
scheme.
• ACPI-defined power states(C1, S1, S3, S4, S5 for
Desktop)
• ACPI-defined power states(C1~C4, S1, S3~S5 for Mobile)
• ACPI Power Management Timer
• SMI# generation
• Low Pin Count(LPC) host interface
• PCI Express Interface
• Support PCI Express 1.1
• 6 PCI Express root ports
• Support for full 2.5 Gb/s bandwidth in each direction per
x1 lane
CPU Package Flip-Chip Land Grid Array (FC-LGA8) technology
CPU Core Voltage 1.196 ±0.748
