Acer Aspire Z5600 Series User Manual

42 Chapter 3
Removing the Back Frame
1. See “Removing the Hinge” on page 41.
2. Unstick the EMI Cable Mylar as shown.
CAUTION: Do not remove the EMI Cable completely; the cable is still attached to the device.
3. Disconnect the CPU Power Cable (A), the SATA Power Cable (B), and the HDD Power Cable (C) as shown:
A
B
c
