Chapter 3
49
Removing the Card Reader Board
1.
See “Removing the Control Board
” on page 48.
2.
Disconnect the Card R
eader Board Cabl
e.
3.
Remove three (3) secu
ring screws from the Card Read
er Board.
4.
Lift the Card Reade
r Board clear of the
device.
Step
Size
Quantity
Screw T
ype
Card Reader Board
3
58
60
