Chapter 3 39
Removing the Back Cover
1. See “Removing the Rear Covers” on page 38.
2. Remove the fourteen (14) screws securing the Back Cover.
3. Use both hands to move the Hinge up into the stand position. There is an audible click when the Hinge is
locked in position.
NOTE: In order to lift the Back Cover away, the Hinge must be in the stand position.
Step Size Quantity Screw Type
Back Cover 14
To Next Page
