Chapter 3
57
Removing the TV Tuner Board
1.
See “Removing the Web Camera Board” on page 56.
2.
Disconnect one
(1) cable from the TV Tuner Board.
3.
Remove one (1) securing screw from the TV Tuner Board.
4.
Lift the TV T
uner Board away as shown.
Ste
p
Size
Quantity
Screw T
ype
TV T
uner Board
1
66
68
