Chapter 3 63
Removing the Mainboard
1. See “Removing the Mainboard Cables” on page 62.
2. Remove five (5) securing screws from the Mainboard as shown.
3. Carefully lift the Mainboard clear of the device.
Step Size Quantity Screw Type
Mainboard SCREW M 2.5*4MM 5
