Acer Aspire Z5600 Series User Manual

58 Chapter 3
Removing the WLAN Board
1. See “Removing the TV Tuner Board” on page 57.
2. Disconnect two (2) cables from the WLAN Board as shown.
3. Remove one (1) securing screw from the WLAN Board.
4. Lift the WLAN Board clear of the device.
Step Size Quantity Screw Type
WLAN Board 1
