48
Chapter 3
Removing the Control Board
1.
See “Removing the SSD
Module” on page 47.
2.
Disconnect three (3) cables on the Control Boa
rd as shown
3.
Remove the two (2) screws securing the Control Boa
rd as shown.
4.
Lift the Control Board clear of the device.
Ste
p
Size
Quantity
Screw T
ype
Control Board
2
57
59
