Acer Aspire Z5600 Series User Manual

Chapter 3 41
Removing the Hinge
1. See “Removing the Back Cover” on page 39.
2. Replace the Hinge to the carry position.
3. Remove the six (6) screws securing the Hinge.
4. Lift the Hinge clear of the device.
Step Size Quantity Screw Type
Hinge 6
