Air-conditioning system
PAG ND8 refrigerant oil, X902.013.573.000 250 cm³
Air-conditioning system – The following specifications apply to Vario 1038 to Vario 1050
Windscreen washer
Capacity 18.8 l
Cab – The following specifications apply to Vario 1038 to Vario 1050
Hydraulic system
Max. operating pressure 210 bar
Hydraulic pump flow at rated speed Standard: 165 l/min
Option: 220 l/min
Option: 220 l/min + 210 l/min
Hydraulic system – The following specifications apply to Vario 1038 through to Vario 1050
Rear power lift
Lift cylinder
internal/external diameter
2x 50 mm/110 mm
Lift cylinder stroke 272 mm
ISO 730 three-point linkage attachment CAT 3/4N
Lower links inside widths in accordance with Cat. 2/3 825 mm/965 mm
Distance between the lower linkage coupling points (spreading
dimension)
870 mm/1010 mm
Continuous lifting power at mounting point 98.5 kN
Maximum lifting power at mounting point 192.2 kN
max. implement weight 7769 kg
Specifications apply to: Vario Vario 1038 - Vario 1050
4.1.6 Technical data: Compressed air system, Electrics & Front power lift
Electrical system
Operating voltage 12 V
Battery 2x 180 Ah/12 V
Alternator 14 V/270 A
4. TECHNICAL DATA
Maintenance 247
530.020.020.011 Rev.A
