2.6 Cooling system
2.6.1 Clean the cooling system
Clean radiator
1.
Open the bonnet.
(A) Air conditioning condenser
(B) Lower part: gearbox oil cooler
(B) Upper part: intercooler
(C) Water cooler
(D) Fuel cooler (hidden)
2.
Swivel the air conditioning condenser (A) to
the side.
3.
Carry out cleaning of the engine side using a
long-handled brush or compressed air.
4.
For stubborn dirt, pre-clean with a soft brush
using a suitable cleaning solution (e.g. "P3").
Leave to work for five minutes, then rinse off
with water.
Fig. 27
5.
Also clean the oil cooler for the front axle (A)
with compressed air.
Fig. 28
2.6.2 Check the coolant level
NOTE: The coolant level must be checked via the display on the terminal and not at the expansion tank.
2. Service and maintenance
36 Maintenance
530.020.020.011 Rev.A
