4263B
External
DC
Bias
Terminal
The
Ext
(External)
DC
Bias terminal
is used
to input
aDC
bias from
an external
source when
DC
bias
setup
is
set to
Ext .
The external
voltage range
is 0
Vto
+2.5 V
.
Caution
Do not
apply External
DC bias
voltage
more
than
+2.5
V
.
Doing
so
will
damage
the
4263B
LINE
Fuse
Holder
The
4263B
's
line
fuse
is
selected
depending
on
the
LINE V
oltage selection.
Refer to
T
able
3-3
LINE
Voltage
Selector
The
Line V
oltage
Selector
is
used
to
match
the
4263B
to
the
power
line
voltage
being
used.
The
line
voltage
selections
are
as follows:
T
able
3-3.
Line
V
oltage
selection
V
oltage
Selector
Line
V
oltage
Required
Fuse
115V 100/120V
ac(
6
10%)
UL/CSA
type
,
Time
delay
0.5A
250V
(Agilent
part
number
2110-0202)
230V 220/240V
ac(
6
10%)
UL
CSA
type
,
Time
delay
0.25A
250V
(Agilent
part
number
2110-0201)
Serial
Number
Plate
The
Serial
Number
Plate
provides
manufacturing
information
about
the
instrument.
F
or
details
,
see
\Serial
Number"
in
Figure
A
-1.
P
ower
Cord
Receptacle
The
P
ower
Cord
Receptacle
is used
to plug
in the
power cord.
P
ower
Code
The 4263B is equipped
with a three-conductor power cord that, when plugged into the
appropriate A
C power receptacle
, grounds the instrument. The oset pin on the power cord is
the safety ground.
3-22 Function Reference and Technical Information
