Troubleshooting the Kinetix 6000 Drive System Chapter 7
E79
DriveOvervoltage Fault
(Shunt Module Flt)
Over-temperature fault indicator on Bulletin 2094 shunt module is steady red.
Refer to Temperature Fault Status Indicator on
page 174.
Shunt-fault indicator on Bulletin 2094 shunt module is steady red. Refer to Shunt Fault Status Indicator on page 174
.
Bulletin 2094 shunt module is missing from power rail.
• Install missing module on power rail.
• Fill empty slot with slot-filler module.
E80
DriveHardFault
(CPLD Flt)
Control hardware fault detected. Replace module.
E81
DriveHardFault
(Common Bus Flt)
Follower IAM module detected AC input power being applied.
Remove AC input power connections from follower
IAM module.
E90
DriveHardFault
(Precharge Timeout Flt)
Precharge resistor power exceeds the resistor rating. Wait for resistor to cool.
E95
IPIMFault
(IPIM Module Flt)
A fault has occurred in one or more IPIM modules on the power rail.
Refer to the troubleshooting chapter in the
Kinetix 6000M Integrated Drive-Motor System
User Manual, publication 2094-UM003
.
Table 102 - Seven-segment Status Indicator Error Codes (continued)
Error
Code
Fault Message - Logix
Designer (HIM)
Anomaly or Symptom Potential Cause Possible Resolution
