28 Rockwell Automation Publication 2094-UM001J-EN-P - March 2017
Chapter 2 Plan the Kinetix 6000 Drive System Installation
Circuit Breaker/Fuse Options
The 2094-xCxx-Mxx-S and 2094-xMxx-S drive modules, and the
Kinetix 6000M integrated drive-motor system (2094-SEPM-B24-S IPIM
module and MDF-SBxxxxx IDM units) use internal solid-state motor short-
circuit protection and, when protected by suitable branch circuit protection,
are rated for use on a circuit capable of delivering up to 200,000 A (fuses) and
65,000 A (circuit breakers).
Table 8 - Control and DC-bus Circuit Protection Specifications
Input Power Circuit Protection (LIM)
The 2094-AL09 and 2094-BL02 line interface modules (LIM) contain
supplementary protection devices and, when protected by suitable branch
circuit protection, are rated for use on a circuit capable of delivering up to 5000
A. When these modules are used, protection on the line side of the LIM
module is required. Fuses must be class J or CC only.
The 2094-ALxxS, 2094-BLxxS, and 2094-XL75S-Cx LIM modules contain
branch circuit rated devices suitable for use on a circuit capable of delivering up
to 65,000 A (400V-class) or 100,000 A (200V-class).
Refer to the Line Interface Module Installation Instructions, publication
2094-IN005
, for power specifications and more information on using the LIM
module.
Refer to Input Power Circuit Protection (without LIM) on page 29
when your
drive system does not include the LIM module.
IAM Module
Cat. No.
Control Input Power DC-bus Power
Bussmann Fuse
(1)
Allen-Bradley® Circuit Breaker
(2)
(non-UL)
Bussmann Fuse Mersen Fuse
(3)
2094-AC05-MP5-S
FNQ-R-10 (10 A)
1492-SPM2D060
N/A A50P20-1
2094-AC05-M01-S
2094-AC09-M02-S FWH-35B A50P35-4
2094-AC16-M03-S
1492-SPM2D200
FWH-60B A50P60-4
2094-AC32-M05-S FWH-125B A50P125-4
2094-BC01-MP5-S
FNQ-R-10 (10 A) or
FNQ-R-7.5 (7.5 A)
1492-SPM2D060 or
1492-SPM1D150
FWJ-20A14F DCT20-2 HSJ20
2094-BC01-M01-S
2094-BC02-M02-S FWJ-40A A70QS40-4 HSJ40
2094-BC04-M03-S FWJ-70A A70QS70-4 HSJ70
2094-BC07-M05-S FWJ-125A A70QS125-4 HSJ125
(1) Use FNQ-R-7.5 circuit breaker for higher single -cycle inrush current capability. This is recommended when the continuous control-power current exceeds 3.0 A.
(2) Use 1492-SPM1D150 circuit breaker for higher single -cycle inrush current capability. This is recommended when the continuous control-power current exceeds 3.0 A.
(3) Mersen fuses were formerly known as Ferraz Shawmut.
