Plan the Kinetix 6000 Drive System Installation Chapter 2
Input Power Circuit Protection (without LIM)
The fuses and Allen-Bradley circuit breakers shown in Table 9 are recommended for use with 2094-xCxx-Mxx-S IAM
modules when the line interface module (LIM) is not used.
Table 9 - Input Power Circuit Protection Specifications
Refer to the Kinetix Servo Drives Technical Data, publication KNX-TD003, for additional power specifications for your
IAM module.
IMPORTANT LIM Modules (catalog numbers 2094-ALxxS, 2094-BLxxS, and 2094-XL75S-Cx) provide branch circuit protection to the IAM
module. Follow all applicable NEC and local codes.
Kinetix 6000 Drives UL Applications IEC (non-UL) Applications
IAM Module
Cat. No.
Drive Voltage
(three-phase)
nom
Fuses (Bussmann)
Cat. No.
Miniature CB
Cat. No.
Motor Protection CB,
Self-protected CMC
Cat. No.
Molded Case CB
Cat. No.
Miniature CB
Cat. No.
Motor Protection CB
Cat. No.
Molded Case CB
Cat. No.
2094-AC05-MP5-S 230V
KTK-R-20 (20 A)
Class CC
1489-M3D300
140M-F8E-C16
NA
1492-SPM3D300 1489-M3D300
140M-F8E-C16
NA2094-AC05-M01-S 230V
KTK-R-20 (20 A)
Class CC
140M-F8E-C16 140M-F8E-C16
2094-AC09-M02-S 230V
KTK-R-30 (30 A)
Class CC
1489-M3D400 140M-F8E-C20 1492-SPM3D400 1489-M3D400 140M-F8E-C20
2094-AC16-M03-S 230V
LPJ-45SP (45 A)
Class J
N/A NA
140G-G6C3-C50
N/A N/A NA
140G-G6C3-C50
2094-AC32-M05-S 230V
LPJ-80SP (80 A)
Class J
140G-G6C3-C90 140G-G6C3-C90
2094-BC01-MP5-S 360…480V
KTK-R-20 (20 A)
Class CC
1489-M3D300
140M-F8E-C32
NA
1492-SPM3D300 1489-M3D300
140M-F8E-C32
NA2094-BC01-M01-S 360…480V
KTK-R-20 (20 A)
Class CC
140M-F8E-C32 140M-F8E-C32
2094-BC02-M02-S 360…480V
KTK-R-30 (30 A)
Class CC
1489-M3D400 140M-F8E-C45 1492-SPM3D400 1489-M3D400 140M-F8E-C45
2094-BC04-M03-S 360…480V
LPJ-45SP (45 A)
Class J
N/A NA
140G-G6C3-C50
N/A N/A NA
140G-G6C3-C50
2094-BC07-M05-S 360…480V
LPJ-80SP (80 A)
Class J
140G-G6C3-C90 140G-G6C3-C90
