CIP Axis Attributes
252 Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018
Converter Output Current
Usage Access T Data
Type
Default Min Max Semantics of Values
Optional - BD Get/GSV T REAL - - - Amps
The Converter Output Current is the output current generated by the Bus
Converter. A positive value indicates current flow out of the converter, where the
converter is supplying DC bus power to attached loads. A negative value indicates
current flow into the converter, where the converter is absorbing "regenerative"
power from attached loads.
Converter Output Power
Usage Access T Data
Type
Default Min Max Semantics of Values
Optional - BD Get/GSV T REAL - - - Power Units
The Converter Output Power is the output power generated by the Bus
Converter. This value is based on the product of the Converter Output Current
and DC Bus Voltage. A positive value indicates power flow out of the converter,
where the converter is supplying DC bus power to attached loads. A negative value
indicates power flow into the converter, where the converter is absorbing
"regenerative" power from attached loads.
See also
Drive General Purpose I/O Attributes on page 249
Power and Thermal Management Configuration Attributes on page 252
These are the power and thermal configuration related attributes associated with a
Motion Control Axis.
Motor Overload Action
Usage Access T Data
Type
Default Min Max Semantics of Values
Optional - D Set/SSV USINT 0 - - Enumeration
0 = None (R)
1 = Current Foldback (O)
2...127 = Reserved
128...255 = Vendor specific
The Motor Overload Action attribute selects the device's response to a motor
overload condition based on an I
2
T or motor thermal model based overload
Power and Thermal
Management Configuration
Attributes
