Allen-Bradley ControlLogix Reference Manual

Chapter 4
CIP Axis Attributes
292 Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018
Exception User Limit Configuration Attributes on page 292
These are the exception user limit configuration related attributes associated with
a Motion Control Axis.
Motor Phase Loss Limit
Usage Access Data
Type
Default Min Max Semantics of Values
Optional - D Set/SSV REAL 5 0 100 % Motor Rated
Sets the minimum motor phase current for the Motor Phase Loss exception. The
current in each motor phase must exceed this value during the motor phase loss
test or a Motor Phase Loss exception occurs. Decreasing this attribute's value
lowers sensitivity to phase loss conditions. A value of 0 will effectively disable the
motor phase loss test.
Motor Overspeed User Limit
Usage Access Data
Type
Default Min Max Semantics of Values
Optional - D Set/SSV REAL FD 0
% Motor Rated
Sets the Overspeed User Limit relative to the Rotary Motor Rated Speed or Linear
Motor Rated Speed that is allowable before throwing a Motor Overspeed UL
exception.
Motor Thermal Overload User Limit
Usage Access Data
Type
Default Min Max Semantics of Values
Optional - D Set/SSV REAL 110 0
% Motor Rated
Sets User Limit for the Motor Thermal Overload UL exception.
Inverter Thermal Overload User Limit
Usage Access Data
Type
Default Min Max Semantics of Values
Optional - D Set/SSV REAL 110 0
% Inverter Rated
Sets User Limit for the Inverter Thermal Overload UL exception.
Exception User Limit
Configuration Attributes
