Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 289
Error
Code
(hex)
Error Name Description of Error
11 Reply data too large
The data to be transmitted in the response buffer is larger than
the allocated response buffer, therefore, no data was transferred.
12 Fragmentation of a primitive value
The service specified an operation that is going to fragment a
primitive data value, for example, halve a REAL data type.
13 Not enough data
The service did not supply enough data to perform the specified
operation.
14 Undefined attribute The attribute specified is not defined for the class or object.
15 Too much data
The service supplied more data than was expected (depending on
the service and the object, the service may still be processed).
16 Object does not exist The object specified does not exist in the device.
17
Service fragmentation sequence not
currently in progress
The fragmentation sequence for this service is not currently active
for this data.
18 No stored attribute data
The attribute data of this object was not saved prior to the
requested service.
19 Store operation failure
The attribute data of this object was not saved due to some failure
during the attempt.
1A
Bridging failure, request packet too
large for network
The service request packet was too large for transmission on a
network in the path to the destination. The bridge device was
forced to abort the service.
1B
Bridging failure, response packet too
large for network
The service response packet was too large for transmission on a
network in the path from the destination. The bridge device was
forced to abort the service.
1C Missing attribute list entry data
The service did not supply an attribute in a list of attributes that
was needed by the service to perform the requested behavior.
1D Invalid attribute value list
The service is returning the list of attributes supplied with status
information for those attributes that were invalid.
1E Embedded service error An embedded service resulted in an error.
1F Connection Related Failure
A service failed because of an error condition related to the
processing of a connection related service. This can occur during
connected and unconnected messaging. The same extended
status codes used for General Status Error Code 01 are returned for
this error's extended status.
20 Invalid Parameter Obsolete
21
Write–once value or medium already
written
An attempt was made to write to a write-once medium (for
example, WORM drive, PROM) that has already been written, or to
modify a value that cannot be changed once established.
22 Invalid Reply Received
An invalid reply is received, for example, reply service code does
not match the request service code, or reply message is shorter
than the minimum expected reply size. This error code can serve
for other causes of invalid replies.
23 CST not coordinated
The Coordinated System Time (CST) value is not yet within the
tolerance where it can accept an update. Try again.
24 Connection Scheduling Error Obsolete
25 Key Failure in IOI
The Key Segment which was included as the first segment in the
IOI does not match the destination module. The object specific
status will indicate which part of the key check failed.
