Allen-Bradley ControlLogix Reference Manual

CIP Axis Attributes
Chapter 4
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 403
Usage Access Data
Type
Default Min Max Semantics of Values
1
This parameter has a strong motor temperature component that some drives circumvent through various adaptive control
or compensation techniques.
* Indicates the attribute cannot be set while the drive power structure is enabled (Power Structure Enable bit in CIP Axis
Status is true).
The Induction Motor Magnetization Reactance attribute is a floating point value
that specifies the Y circuit, phase-neutral, magnetizing reactance of the motor, at
rated frequency, as shown as X
m
in the IEEE motor model.
Induction Motor Rotor Resistance
Usage Access Data
Type
Default Min Max Semantics of Values
Optional
1
Set/SSV* REAL 0
DB
0
Ohms
1
This parameter has a strong motor temperature component that some drives circumvent through various adaptive control
or compensation techniques.
* Indicates the attribute cannot be set while the drive power structure is enabled (Power Structure Enable bit in CIP Axis
Status is true).
The Induction Motor Rotor Resistance attribute is a floating point value that
specifies the phase-neutral equivalent stator-referenced winding resistance of the
rotor as shown as R
2
' in the IEEE motor model.
Induction Motor Rotor Leakage Resistance
Usage Access Data
Type
Default Min Max Semantics of Values
Optional Set/SSV* REAL 0
DB
FD
0
Ohms
* Indicates the attribute cannot be set while the drive power structure is enabled (Power Structure Enable bit in CIP Axis
Status is true).
The Induction Motor Rotor Leakage Resistance attribute is a floating point value
that specifies the Y circuit, phase-neutral, equivalent stator-referenced leakage
inductance of the rotor winding, at rated frequency, as shown as X
2
' in the IEEE
motor model.
Induction Motor Rated Slip Speed
Usage Access Data
Type
Default Min Max Semantics of Values
Optional Set/SSV* REAL 0
FD
0
RPM (rotary motor type)
m/s (linear motor type)
* Indicates the attribute cannot be set while the drive power structure is enabled (Power Structure Enable bit in CIP Axis
Status is true).
