Publication 1763-RM001C-EN-P - October 2009
118 Using the High-Speed Counter and Programmable Limit Switch
HSL - High-Speed
Counter Load
Instruction Type: output
The HSL (High-Speed Load) instruction allows the high and low presets,
and high and low output source to be applied to a high-speed counter.
These parameters are described below:
• Counter Number - Specifies which high-speed counter is being
used; 0=HSC0 and 1=Not support.
• High Preset - Specifies the value in the high preset register. The data
ranges for the high preset are -32768 to 32767 (word) and
-2,147,483,648 to 2,147,483,647 (long word).
• Low Preset - Specifies the value in the low preset register. The data
ranges for the low preset are -32768 to 32767 (word) and
-2,147,483,648 to 2,147,483,647 (long word).
• Output High Source - Specifies the value in the HPO - high preset
output register. The data range for the output high source is from 0
to 65,535.
• Output Low Source - Specifies the value in the LPO - low preset
output register. The data range for the output low source is from 0
to 65,535.
Valid Addressing Modes and File Types are shown below:
HSL
High Speed Counter Load
HSC Number HSC0
High Preset N7:0
Low Preset N7:1
Output High Source N7:2
Output Low Source N7:3
HSL
Controller Data Size Execution Time When Rung Is:
True False
MicroLogix 1100 word 82.37 μs 0.87 μs
long word 84.37 μs 0.87 μs
HSL Instruction Valid Addressing Modes and File Types
For definitions of the terms used in this table see Using the Instruction Descriptions on page 82.
Parameter
Data Files Function Files
CS - Comms
IOS - I/O
DLS - Data Log
Address
Mode
Address Level
O
I
S
B
T, C, R
N
F
ST
L
MG, PD
RI/RIX
PLS
RTC
HSC
PTO, PWM
STI
EII
BHI
MMI
LCD
Immediate
Direct
Indirect
Bit
Word
Long Word
Element
Counter Number • •
High Preset •• ••• • • • • •••
Low Preset •• ••• • •
• • •••
Output High Source • • • • • • •
• • •••
Output Low Source • • • • • • •
• • •••
