1-28 Installation/Wiring
Essential Requirements for CE Compliance
Conditions 1-4 listed below must be satisfied for PowerFlex drives to
meet the requirements of EN61800-3.
1. Grounding as described in Figure 1.11
. Refer to page 1-9 for
additional grounding recommendations.
2. Output power, control (I/O) and signal wiring must be braided,
shielded cable with a coverage of 75% or better, metal conduit or
equivalent attenuation.
3. All shielded cables should terminate with the proper shield
connector.
4. Conditions in Table 1.J
.
Table 1.J PowerFlex 400 – EN61800-3 Compliance
PowerFlex 400 Drive First Environment Restricted First Environment Unrestricted
kW (HP) Cat. No.
22C-…
Required Filter
(Allen-Bradley)
Restrict
Motor
Cable to
(Meters)
Install
Drive and
Filter in
Shielded
Enclosure
Required Filter Restrict
Motor
Cable to
(Meters)
Install
Drive and
Filter in
Shielded
Enclosure
200-240 Volts
2.2 (3.0) B012N103 22-RF034-CS 10 No 22-RF034-CS 1 Required
3.7 (5.0) B017N103 22-RF034-CS 10 No 22-RF034-CS 1 Required
5.5 (7.5) B024N103 22-RF034-CS 10 No 22-RF034-CS 1 Required
7.5 (10) B033N103 22-RF034-CS 10 No 22-RF034-CS 1 Required
11 (15) B049A103 22-RFD070 150 Required Deltron MIF Series 50 Required
15 (20) B065A103 22-RFD100 150 Required Deltron MIF Series 50 Required
18.5 (25) B075A103 22-RFD100 150 Required Deltron MIF Series 50 Required
22 (30) B090A103 22-RFD150 150 Required Deltron MIF Series 50 Required
30 (40) B120A103 22-RFD150 150 No Deltron MIF Series 50 Required
37 (50) B145A103 22-RFD180 150 No Deltron MIF Series 75 Required
380-480 Volts
2.2 (3.0) D6P0N103 22-RF018-CS 10 No 22-RF018-CS 1 Required
4.0 (5.0) D010N103 22-RF018-CS 10 No 22-RF018-CS 1 Required
5.5 (7.5) D012N103 22-RF018-CS 10 No 22-RF018-CS 1 Required
7.5 (10) D017N103 22-RF018-CS 10 No 22-RF018-CS 1 Required
11 (15) D022N103 22-RF026-CS 10 No 22-RF026-CS 1 Required
15 (20) D030N103 22-RFD036 100 No Deltron MIF Series 5 Required
18.5 (25) D038A103 22-RFD050 150 No Deltron MIF Series 5 Required
22 (30) D045A103 22-RFD050 150 No Deltron MIF Series 5 Required
30 (40) D060A103 22-RFD070 50 No Deltron MIF Series 5 Required
37 (50) D072A103 22-RFD100 50 No Deltron MIF Series 5 Required
45 (60) D088A103 22-RFD100 50 No Deltron MIF Series 5 Required
55 (75) D105A103 22-RFD150 150 No Deltron MIF Series 5 Required
75 (100) D142A103 22-RFD180 50 No Deltron MIF Series 5 Required
90 (125) D170A103 Consult Factory Consult Factory
110 (150) D208A103 Consult Factory Consult Factory
