Atlas Copco FlexiROC T30 R Maintenance

FlexiROC T30 R 10 Hydraulic System
66 No: 3629357835.1.3629419915 en-US
!
NOTE: The electric filler pump stops automatically when the hy-
draulic tank is full. It also stops if the source of oil runs out.
10.7.4 Emptying Hydraulic Oil Tank
1.
Open the breather filter in the top of the hydraulic oil tank.
2.
Remove the plug from the ball valve (A) under the hydraulic tank.
3.
Connect a hose to the ball valve and place the other end of the hose into a vessel.
4.
Open the ball valve and empty the tank.
5.
Close the ball valve after all oil is drained.
6.
Disconnect the hose.
7.
Close the breather filter.
8.
Reinstall the plug on the ball valve.
10.7.5 Filling Hydraulic Oil
WARNING
Hydraulic Oil Under Pressure
There is a risk of personal injury when working with pressurized hydraulic systems.
u Use personal protective equipment.
!
NOTE: Do not fill up with too much hydraulic oil as it can then clog the ventilation filter.
