Atlas Copco FlexiROC T30 R Maintenance

FlexiROC T30 R 11 Diesel Engine
82 No: 3629357835.1.3629419915 en-US
3.
Undo the two bolts (C) to remove the pump.
4.
Replace a belt by inserting it through the gap between the coupling rubber and the
shaft flange.
5.
Tighten the bolts (C).
6.
Screw back the coupling rubber and tighten the bolts (B) (185 Nm).
7.
Install the belt cover.
11.14 Lubricate V-Belt Pulley PTO
If lubricant leaks out around the bearing during the first three years, there is a need to add
some extra lubricant.
1.
Lubricate 1/4 to 1/3 gram or 1/4 to 1/3 pump stroke per lubrication.
!
NOTE: Special tools must be used when replacing bearings. Con-
tact Atlas Copco for information about how to proceed.
See Reference Documentation
Diesel engine instruction manual
