200
71.07144.01 - SK
POKYNY PRE INŠTALATÉROV
30. SCHÉMA PRIPOJENIA KONEKTOROV
24 F
Farba vodičov
C = Svetlomodrá
M = Hnedá
N = Čierna
R = Červená
G/V = Žltozelená
B = Biela
V – Zelená
ZAPAĽOVACIA ELEKTRÓDA/
KONTROLA PLAMEŇA
TERMOSTAT
ČERPADLO
VENTILÁTOR
SENZOR
PREDNOSTI TÚV
VONKAJŠIA
SONDA
HYDRAULICKÝ
TLAKOVÝ SPÍNAČ
POISTNÝ
TERMOSTAT
VZDUCHOVÝ
TLAKOVÝ SPÍNAČ
PRIESTOROVÝ TERMOSTAT/
DIAĽKOVÉ OVLÁDANIE
HASZN. MELEGVÍZ
NTC SZONDA
SONDA NTC
KÚRENIA
