MODELS 13U100, 13U200
Engine Specifications
ENGINE
2.76 in (70 mm)Bore
2.13 in (54 mm)Stroke
12.69 ci (208 cc)Displacement
8:5:1Compression Ratio
0.003-0.030 in (0.09-0.75 mm)Crankshaft End Play
0.002-0.009 in (0.05-0.23 mm)Crankshaft End Play (Pump Applications)
19-22 oz (550-650 ml)Oil Capacity
3.17 qt (3.0 L)Fuel Tank Capacity
24° BTDCIgnition Timing
0.008-0.016 in (0.20-0.40 mm)Armature Air Gap
0.028-0.035 in (0.70-0.90 mm)Spark Plug Gap
0.005-0.007 in (0.13-0.18 mm)Valve Clearance - Intake
0.005-0.007 in (0.13-0.18 mm)Valve Clearance - Exhaust
0.059-0.071 in (1.5-1.8 mm)Crankcase MAG Bearing Oil Seal Depth
0.118-0.130 in (3.0-3.3 mm)Crankcase Cover PTO Bearing Oil Seal Depth
Torque Specifications
TORQUEFASTENER
4-13 lb-in (0.5-1.5 N-m)Air Cleaner Cover Screw (Paper Air Filter)
71-124 lb-in (8-14 N-m)Air Cleaner Base to Governor Bracket Screw
35-71 lb-in (4-8 N-m)Air Cleaner Base Nut
71-124 lb-in (8-14 N-m)Armature Screw
71-124 lb-in (8-14 N-m)Blower Housing Screw
44-62 lb-in (5-7 N-m)Carburetor Stud
49-80 lb-in (5.5-9 N-m)Carburetor Drain Plug
49-80 lb-in (5.5-9 N-m)Carburetor Sediment Bowl Nut
124-142 lb-in (14-16 N-m)Connecting Rod Cap Screw
18-19 lb-ft (24-26 N-m)Crankcase Cover Screw *
21-22 lb-ft (28-30 N-m)Cylinder Head Screw *
71-124 lb-in (8-14 N-m)Cylinder Heat Shield Screw
71-124 lb-in (8-14 N-m)Flywheel Guard Screw
54-59 lb-ft (73-80 N-m)Flywheel Nut
71-124 lb-in (8-14 N-m)Fuel Tank Screw
71-124 lb-in (8-14 N-m)Fuel Tank Nut
62-71 lb-in (7-8 N-m)Fuel Tank Fuel Filter Fitting
71-124 lb-in (8-14 N-m)Governor Bracket Screw
71-124 lb-in (8-14 N-m)Governor Lever Nut (Nyloc)
35-71 lb-in (4-8 N-m)Low Oil Sensor Module Screw
71-124 lb-in (8-14 N-m)Low Oil Sensor Screw
71-124 lb-in (8-14 N-m)Low Oil Sensor Nut
35-62 lb-in (4-7 N-m)Muffler Stud
195-266 lb-in (22-30 N-m)Muffler Stud Nut
