Final Instructions
1. Install oil drain plug(s) with sealing washer(s) and
tighten as follows.
Oil Drain Plug
TorqueModels
140-200 lb-in (15.8-22.6 N-m)130G00, 131G00, 13R200
248-266 lb-in (28-30 N-m)13U100, 13U200
2. Add engine oil. See
SECTION 2 - MAINTENANCE,
CHANGE ENGINE OIL/CHECK ENGINE OIL LEVEL,
steps 7-12.
3. Fill fuel tank with fresh gasoline.
4. Route spark plug wire forward under breather hose,
and then upward to install onto spark plug terminal.
5. Start and run engine. Check for oil and fuel leaks while
engine is running.
Adjust Idle Speed
1. See Figure 137. Obtain Digital Tachometer and Hour
Meter (Part No. 19598) (A). Proceed as follows:
A. Insert solder lug of white wire under engine or frame
bolt for suitable ground (B).
137
B. Tightly coil red wire over an insulated section of the
spark plug wire using three to four turns (C).
NOTE: Keep wires away from hot or moving engine
parts.
2. Start and run engine for five minutes (D).
3. Move throttle control lever to SLOW (E).
4. Hold throttle lever (F) against idle screw (G) and adjust
idle screw to obtain 1450 RPM.
5. Stop engine and remove Digital Tachometer and Hour
Meter.
Adjust Top No-Load Speed
1. Obtain the Top No-Load Speed for the engine. Proceed
as follows:
A. Dealers: See
www.thepowerportal.com.
B. Consumers: Contact your local Briggs & Stratton
authorized service dealer.
NOTE: Have your complete model-type-trim
number and code number in hand.
138
92
8
