6. Saturate foam filter with clean engine oil. Gently
squeeze foam filter in a clean cloth to remove excess
oil.
7. Install foam filter into air cleaner cover (C).
8. Install air cleaner cover and engage two retaining clips
(D) to secure.
130
Paper Air Filter
1. See Figure 131. Install air cleaner base (A) onto
carburetor mounting studs.
2. Install two hex flange nuts onto carburetor mounting
studs. Alternately tighten nuts to 30-50 lb-in (3.4-5.7
N-m).
3. Install breather hose from valve cover to port on air
cleaner base.
4. Gently tap filter (B) on a hard surface to loosen dust
and dirt. Replace if it cannot be adequately cleaned or
if any damage is observed.
5. If equipped, wash pre-cleaner (C) in warm, soapy water.
Thoroughly rinse with clean water and allow to air dry
completely. Do not oil pre-cleaner.
6. Install pre-cleaner and filter.
7. Install air cleaner cover (D) and start two hex flange
screws (E). Alternately tighten screws to 9-12 lb-in
(1-1.4 N-m).
131
89
8
