Playback
Playback
This section explains how to play back clips recorded on a CF card. For details on playing back clips using an
external monitor, refer to
Connecting to an External Monitor (A 140). For details on viewing photos on the SD
card, refer to
Viewing Photos (A 153).
Clip Index Screen
Playback functions are accessed from the clip index screen. To open the
clip index screen, set the camcorder to mode. If the CF card
contains a type of recordings (NTSC/PAL/24.00P) different from the
camcorder’s current settings, you will not be able to play back the clips. In
such case, change the [w Other Functions] > [24.00P] or [NTSC/PAL]
settings as necessary (A 59).
Set the Q switch to MEDIA.
• The camcorder switches to mode and the clip index screen appears.
Operating modes:
7 8
12
11
2
1
4
13
9
10
3
6
5
14
15 16
COPY

Canon EOS C300 Specifications

General

Sensor type	CMOS
Total megapixels	9.84 MP
Optical sensor size	- \
Effective megapixels (movie)	8.29 MP
Optical zoom	- x
Image stabilizer	No
Interchangeable lens	Yes
Lens mount interface	Canon EF
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	CF, SD, SDHC
Internal storage capacity	- GB
Display diagonal	4 \
Viewfinder type	-
Viewfinder screen size	0.52 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Product color	Black
Video formats supported	MPEG2, MXF
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
Microphone connectivity	XLR
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Battery capacity	- mAh
Battery life (max)	- h
Operating temperature (T-T)	5 - 45 °C

Weight and Dimensions

Depth	179 mm
Width	133 mm
Height	171 mm
Weight	1430 g
