Canon EOS C300 User Manual

6
139
External Connections
Video Output Configuration
The video signal output from the HD/SD SDI, HDMI OUT and SYNC OUT terminals depends on the clip’s video
configuration, the capability of the external monitor (for video output from the HDMI OUT terminal) and on various
menu settings.
Video Output Configuration by Terminal
Refer to the following table for the video output configuration from each terminal. If necessary, you can
superimpose the onscreen displays on the video displayed on the external monitor (A 142).
Operating modes:
Video Output Configuration by Terminal
1
Set [¢ Video Setup] > [SDI Output] to [HD], [SD] or [Off].
2
When you set [£ LCD/VF Setup] > [Zebra HD Output] to [On], you can display zebra patterns on an external monitor. (HD
output only. During SD output the zebra pattern will not be output.)
3
Video output will automatically switch to HD or SD, depending on the capability of the external monitor.
4
Set [¢ Video Setup] > [SYNC Output] to [HD-Y] (HD component video, luminance signal) or [Composite] (SD analog
composite signal).
5
When the camcorder is connected via HDMI OUT terminal to an external monitor, the video signal output from the HD/SD SDI
terminal will be the same as that from the HDMI OUT terminal.
Terminal J
Video configuration L
HD/SD SDI
1, 2
HDMI OUT
2, 3
SYNC OUT
4
Type of
recording
Resolution (vertical)/Frame rate HD output SD Output
5
HD output SD output HD Output SD Output
24.00P
1080/24.00P 1080/60.00i – 1080/60.00i – 1080/60.00i –
720/24.00P 720/60.00P – 720/60.00P – 720/60.00P –
NTSC
1080/59.94i
1080/59.94i 480/59.94i 1080/59.94i 480/59.94P 1080/59.94i 480/59.94i
1080/29.97P
1080/23.98P
1080/slow or fast motion
720/59.94P
720/59.94P 480/59.94i 720/59.94P 480/59.94P 720/59.94P 480/59.94i
720/29.97P
720/23.98P
720/slow or fast motion
PAL
1080/50.00i
1080/50.00i 576/50.00i 1080/50.00i 576/50.00P 1080/50.00i 576/50.00i1080/25.00P
1080/slow or fast motion
720/50.00P
720/50.00P 576/50.00i 720/50.00P 576/50.00P 720/50.00P 576/50.00i720/25.00P
720/slow or fast motion
COPY

Canon EOS C300 Specifications

General

Sensor type	CMOS
Total megapixels	9.84 MP
Optical sensor size	- \
Effective megapixels (movie)	8.29 MP
Optical zoom	- x
Image stabilizer	No
Interchangeable lens	Yes
Lens mount interface	Canon EF
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	CF, SD, SDHC
Internal storage capacity	- GB
Display diagonal	4 \
Viewfinder type	-
Viewfinder screen size	0.52 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Product color	Black
Video formats supported	MPEG2, MXF
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
Microphone connectivity	XLR
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Battery capacity	- mAh
Battery life (max)	- h
Operating temperature (T-T)	5 - 45 °C

Weight and Dimensions

Depth	179 mm
Width	133 mm
Height	171 mm
Weight	1430 g
