Canon EOS C300 User Manual

Setting the Time Code
84
Setting the Time Code
In mode, the camcorder can generate a time code signal and embed it in your recordings. You can have
the camcorder output the time code signal from the HD/SD SDI terminal or TIME CODE terminal (A 90). In
mode, you can output the time code of the clip being played back through the same terminals.
Additionally, you can superimpose the time code on video output from the HDMI OUT terminal or SYNC OUT
terminal. For NTSC recordings, you can also select between a drop frame and non-drop frame time code.
To synchronize the camcorder’s time code to an external time code generator, refer to
Synchronizing with an
External Device
(A 88).
Selecting the Running Mode
You can select the running mode of the camcorder’s time code.
1 Open the time code [Mode] submenu.
[¤ TC/UB Setup] > [Time Code] > [Mode]
2 Select the desired option and then press SET.
• If you selected [Regen.], you do not need to perform the rest of this
procedure. If you selected [Preset] and would like to set the time
code’s initial value, see the following section
Setting the Time Code’s
Initial Value
.
3 After you select [Preset], open the time code [Run] submenu.
[¤ TC/UB Setup] > [Time Code] > [Run]
4 Select the desired option and then press SET.
Options
Operating modes:
[Preset]: The time code starts from an initial value you can select in
advance. The default initial time code is 00:00:00.00. The time
code’s running mode depends on the [Run] setting.
[Rec Run]: The time code runs only while recording so clips
recorded consecutively on the same CF card will have
continuous time codes.
[Free Run]:The time code starts running the moment you press
SET to select this option and keeps running regardless
of the camcorder’s operation.
[Regen.]: The camcorder will read the selected CF card and the time code
will continue from the last recorded time code on the CF card. The
time code runs only while recording so clips recorded
consecutively on the same CF card will have continuous time
codes.
[¤ TC/UB Setup]
[Time Code]
[Mode]
[Regen.]
[¤ TC/UB Setup]
[Time Code]
[Run]
[Rec Run]
COPY

Canon EOS C300 Specifications

General

Sensor type	CMOS
Total megapixels	9.84 MP
Optical sensor size	- \
Effective megapixels (movie)	8.29 MP
Optical zoom	- x
Image stabilizer	No
Interchangeable lens	Yes
Lens mount interface	Canon EF
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	CF, SD, SDHC
Internal storage capacity	- GB
Display diagonal	4 \
Viewfinder type	-
Viewfinder screen size	0.52 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Product color	Black
Video formats supported	MPEG2, MXF
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
Microphone connectivity	XLR
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Battery capacity	- mAh
Battery life (max)	- h
Operating temperature (T-T)	5 - 45 °C

Weight and Dimensions

Depth	179 mm
Width	133 mm
Height	171 mm
Weight	1430 g
