Canon EOS C300 User Manual

Preparing Recording Media
44
Removing a CF card
1 Wait until the access indicator for the card slot with the CF card
to be removed is off.
2 Slide the CF card slot cover switch in the direction of the arrow.
• The CF card slot cover will open upward (slot A) or downward (slot B).
3 Push the CF card release button.
• The release button partially pops out.
4 Push in the CF card release button to release the CF card.
5 Pull the CF card all the way out and close the CF card slot cover.
IMPORTANT
• Observe the following precautions while the CF2 or CF3 access indicator is illuminated in red. Failure to do
so may result in permanent data loss.
- Do not disconnect the power source or turn off the camcorder.
- Do not open the cover of the CF card slot being accessed.
NOTES
• If you set the [w Other Functions] > [Media Access LED] function to [Off], the access indicators will not
illuminate.
Inserting and Removing an SD Card
1 Turn off the camcorder.
2 Open the SD card slot cover.
3 Insert the SD card all the way into the SD card slot until it clicks.
• The SD card slot is positioned at an angle. Align the SD card straight in
relation to the SD card slot, with the label facing the lens.
4 Close the SD card slot cover.
• Do not force the cover closed if the SD card is not correctly inserted.
IMPORTANT
• Observe the following precautions while the SD card access indicator is flashing. Failure to do so may result in
permanent data loss.
- Do not disconnect the power source or turn off the camcorder.
- Do not remove the SD card.
• Turn off the camcorder before inserting or removing an SD card. Inserting or removing the SD card with the
camcorder on may result in permanent data loss.
• SD cards have front and back sides that are not interchangeable. Inserting an SD card facing the wrong
direction can cause a malfunction of the camcorder. Be sure to insert the SD card as described in step 3.
NOTES
• To remove the SD card: Push the SD card once to release it. When the SD card springs out, pull it all the way
out.
• If you set the [w Other Functions] > [Media Access LED] function to [Off], the access indicators will not
illuminate.
,
SD card access
indicator
COPY

Canon EOS C300 Specifications

General

Sensor type	CMOS
Total megapixels	9.84 MP
Optical sensor size	- \
Effective megapixels (movie)	8.29 MP
Optical zoom	- x
Image stabilizer	No
Interchangeable lens	Yes
Lens mount interface	Canon EF
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	CF, SD, SDHC
Internal storage capacity	- GB
Display diagonal	4 \
Viewfinder type	-
Viewfinder screen size	0.52 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Product color	Black
Video formats supported	MPEG2, MXF
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
Microphone connectivity	XLR
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Battery capacity	- mAh
Battery life (max)	- h
Operating temperature (T-T)	5 - 45 °C

Weight and Dimensions

Depth	179 mm
Width	133 mm
Height	171 mm
Weight	1430 g
