Canon EOS C300 User Manual

37
Preparing the Camcorder
Removing the Monitor Unit
1 Set the Q switch to OFF.
2 Disconnect the monitor unit’s cables from the camcorder’s EXT 1 and EXT 2 terminals.
• Pull back the metallic tips of the cable to release the cable and then disconnect the cable.
3 Unscrew the lock screw and then gently slide out the monitor unit from the accessory shoe.
Using the Viewfinder
Adjusting the Viewfinder’s Position
1 Gently pull out the viewfinder until it stops.
2 Adjust the viewfinder’s angle as necessary.
Attaching and Detaching the Eye Cup
Attach the eye cup so that it covers the rubber portion of the viewfinder
unit.
• The dioptric adjustment dial can be operated even with the eye cup
attached.
• For left eye use, attach the eye cup so that the protruding portion faces
the opposite side.
Detach the eye cup as shown in the illustration.
Eye cup
Viewfinder
unit
COPY

Canon EOS C300 Specifications

General

Sensor type	CMOS
Total megapixels	9.84 MP
Optical sensor size	- \
Effective megapixels (movie)	8.29 MP
Optical zoom	- x
Image stabilizer	No
Interchangeable lens	Yes
Lens mount interface	Canon EF
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	CF, SD, SDHC
Internal storage capacity	- GB
Display diagonal	4 \
Viewfinder type	-
Viewfinder screen size	0.52 \
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Product color	Black
Video formats supported	MPEG2, MXF
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Maximum image resolution	- pixels
PCM digital audio	16-bit/48 kHz
Microphone connectivity	XLR
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Battery capacity	- mAh
Battery life (max)	- h
Operating temperature (T-T)	5 - 45 °C

Weight and Dimensions

Depth	179 mm
Width	133 mm
Height	171 mm
Weight	1430 g
