Canon Laser Shot LBP5000 User Manual

3-55
Printing from a Network Computer by Sharing the Printer on a Network
Setting Up the Printing Environment
3
When using a print server, perform the following settings:
NOTE
Using this printer on your network requires that both the print server and clients should
be using Windows 98/Me or Windows 2000/XP/Server 2003.
Print Server Settings
This section describes the procedure assuming that the print server is running
Windows2000/XP/Server 2003.
NOTE
• If you configure the sharing function of the print server or clients that are running
Windows 98/Me, use the following procedure.
1. Double-click [My Computer] ➞ [Control Panel] ➞ the [Network] icon.
2. Display the [Configuration] sheet, then click [Add].
3. Select the [Service] icon, then click [Add].
4. Select [File and printer sharing for Microsoft Networks], then click [OK].
5. Click [File and Printer Sharing], make sure that [I want to be able to allow others to
print to my printer(s).] is selected, then click [OK].
6. Display the [Access Control] sheet, select [Share-level access control] or
[User-level access control], and then click [OK] to restart Windows.
7. After Windows restarts, from the [Start] menu, select [Settings] ➞ [Printers].
8. Right-click the icon for this printer, then select [Sharing] from the pop-up menu.
9. Select [Shared As]. Change [Share Name] if you want to, then enter [Comment]
and [Password] as needed.
10. Click [OK].
• The screen shots used in this section are from Windows XP Professional.
Setting See
1
Install the printer driver on the print server
- When the printer and print server are connected by
the USB cable
See p. 3-4
- When the optional network board is installed and
the printer and print server are connected by the
LAN cable
See Network Guide
2 Print Server Settings See p. 3-55
3 Installation on Clients See p. 3-62

Canon Laser Shot LBP5000 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (color, normal)	20 s
Print speed (black, normal quality, A4/US Letter)	8 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	125 sheets
Maximum input capacity	500 sheets
Envelopes sizes	B5, C5, DL
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), index card, Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Network ready	-
Power requirements	220 - 240V
Supported media weight(s)	60 - 163 g/m²
Compatible operating systems	Windows 98/Me/2000/XP/Server2003 Mac OS X version 10.2.8 -10.5.x Linux
Power consumption (standby)	18 W
Power consumption (printing)	207 W
Maximum duty cycle	35000 pages per month
Operating temperature (T-T)	10 - 30 °C
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	407 x 365 x 374 mm
